All of the WW, WS and WX units as well as all of the PXI and PCI units can be programmed using Matlab, Labview, and C++. Our IVI driver is on the installation CD provided with the instrument or you can download it from our online download center .

The memory on the units can be upgraded after purchase but please be aware that extra costs such as re-work and shipping will be added to the cost of the memory option.

IVI Shared Components must be installed on the system before Driver installation.

Here is an example:

//Arb wave data
unsigned short waveBuffer[16]={0x0000,0x2000,0x4000,0x6000,0x8000,0xA000,0xC000,0xE000,0xFFFF,0xE000,0xC000,0xA000,0x8000,0x6000,0x4000,0x2000};

//Define Arb segment
strcpy(cmd_str,"TRAC:DEF 1,16\n");
viWrite(InstrSession,(unsigned char *)cmd_str,strlen(cmd_str),0);

//Arb wave header
strcpy(cmd_str,"TRAC:DATA#232");
viWrite(InstrSession,(unsigned char *)cmd_str,strlen(cmd_str),0);
//Write arb wave viWrite(InstrSession,(unsigned char *)waveBuffer,32,0);
