Model PXE21100

21 Slot PXIe Based Chassis with Embedded Controller

The PXE21100 is a 4U, 19in, PXIe based, 21 slot, Gen 4 chassis, that supports the Tabor Proteus Family of AWGs, the TE3xxx family of PXIe RF amplifiers, and other modules that comply with the PXIe standard. The system includes as standard an embedded i5-13500E PC with an internal 128GB SSD drive, Display Port connection, USB interfaces for a mouse and keyboard, as well as control using USB-C and 2.5Gb Ethernet. The PC is upgradeable to an i9-13900E, 256G RAM and 960GB SSD.

Maximize rack space with a high slot count - 21 PXIe slots in 19in 4U
Fastest available data transfer speeds with Gen 4 PCIe support
Built-in computer - i5-13500E, upgradable to i9-13900E
Multi-chassis sync with the PXE21106 - Synchronization Unit
Smart fan and chassis status monitoring
High Speed Connectivity - 2.5GbE, Rear panel RJ45 connector and 3 x USB 2.0 (type A), 1 x USB3.2Gen1 (type A)

Relevant Documents

Data Sheet(2 MB)

Links

View Options and Ordering Information

Related Downloads

Please choose the type of content that you need

Download Type

Description

Version

Release Date

Data Sheets

PXE21100 Datasheet (2 MB)

Ver. 1.2

08/11/2024

Chassis

PXE21100 User Manual (1 MB)

Ver. 1.0

17/05/2024

Manuals

Update Tool User Manual (908 KB)

Ver. 1.3

31/03/2025

Ordering Info

Model	Description
PXE21100	21 Slots Chassis.

Options

Name	Description
COMP	Upgrade to i9-13900E, 256G RAM and 960GB SSD.

Accessories

Name	Description
PXE21106	Multi-Channel Mesh, Synchronization Unit

Note: Options and Accessories must be specified at the time of your purchase.

Features

Formfactor

Size 4U, 19in 438.8mm x 176.0mm x 449.5mm

Embedded Controller

CPU: i5-13500E, upgradable to i9-13900E RAM: 16GB, upgradable to 256GB, and SSD: 128GB, upgradable to 960GB

Backplane

Backplane - PCIe Gen 4 Slots - 21

Scale to Multiple Chassis

Connect multiple chassis for a fully synchronized and phase-coherent system. The dedicated PXE21106, Mesh controller can synchronize up to 6 chassis and enables data transfer between modules in different chassis. For more than 6 chassis simply connect multiple PXE21106 units.
